Product Summary

XCF16PFS48C introduces the Platform Flash series of in-system programmable configuration PROMs. Available in 1 to 32 Mb

densities, these PROMs provide an easy-to-use, cost-effective, and reprogrammable method for storing large Xilinx FPGA

configuration bitstreams.

Parametrics

1.8V Supply Voltage, Serial or Parallel FPGA Configuration Interface,  Available in Small-Footprint VOG48, FS48, and

FSG48 Packages, Design Revision Technology Enables Storing and Accessing Multiple Design Revisions for Configuration.

Built-In Data Decompressor Compatible with Xilinx Advanced Compression Technology.

Features

In-System Programmable PROMs for Configuration of Xilinx FPGAs.

Low-Power Advanced CMOS NOR Flash Process.

Endurance of 20,000 Program/Erase Cycles.

Diagrams
